HIGH PRESSURE AIR COMPRESSORS
| MAINTENANCE KITS | |||
| C200 | C260 | C260H | |
| 500 Hour Kit | FCCC1847 | FCCC1847 | FCCC1885 |
| Gasket Kit | FCMA817 | FCMA817 | FCMA817 |
| Valve Kit | FCO1875 | FCO1875 | FCO1875 |
| Lower End Kit | FCO1931 | FCO1931 | FCO1932 |
| Full Rebuild Kit | FCDB1459 | FCDB1459 | FCDB1462 |
WWW.HKAIRCOMPRESSORS.COM
| PARTS LIST - C200 / C260 / C260H | |||||
| PART NUMBER | |||||
| NO | DESCRIPTION | QTY | |||
| C200 | C260 | C260H | |||
| 1 | C200 CRANKCASE | 1 | FCM828A | < | < |
| 2 | BALANCED C200 / C260 CRANKSHAFT | 1 | FCMA847A | < | < |
| 3 | FLYWHEEL KEY, C200, C260, C260H | 1 | FCM892 | < | < |
| 4 | BELL HOUSING GASKET | 1 | FCM894 | < | < |
| 5 | TAPERED ROLLER BEARING CUP AND CONE | 2 | FVD854 | < | < |
| 6 | SET SCREW, SOCKET 5/16-18 X 3/8 | 2 | FVH1410 | < | < |
| 7 | OIL PUMP CARRIER GEAR | 1 | FCM841 | < | < |
| 8 | OIL PRESSURE ADJ ASSY | 1 | FCM843 | < | < |
| 9 | OIL PUMP KEY | 1 | FCM891 | < | < |
| 10 | MACHINING BEARING PLATE | 1 | FCM836 | < | < |
| 11 | FLANGED BEARING | 1 | FCM834A | < | < |
| 12 | OIL PUMP RETAINING SPRING | 1 | FVO103 | < | < |
| 13 | OIL PUMP CARRIER GEAR | 1 | FCM839 | < | < |
| 14 | OIL PUMP GEAR KEY | 1 | FCM884 | < | < |
| 15 | OIL PUMP | 1 | FVO101 | < | < |
| 16 | PLUG, HEX HEAD CORED, 3/8NPT | 4 | FPTQ03AB | < | < |
| 17 | LARGE END PLATE GASKET | 1 | FCM893 | < | < |
| 18 | LARGE END PLATE | 1 | FCM833 | < | < |
| 19 | HHCS 1/2-13UNC X 3" | 8 | FVH12PT | < | < |
| 20 | MASTER OIL SEAL GASKET | 1 | FCM886 | < | < |
| 21 | OIL SEAL 1-7/8 ID x 2-3/8 OD x 1/4 THICK | 2 | FVB320 | < | < |
| 22 | SOCKET HEAD CAP SCREW, 3/8-16 | 9 | FVH13KH | < | < |
| 23 | INTERNAL SNAP RING, 2-3/8" | 2 | FVH1801 | < | < |
| 24 | O-RING, 1/8", 3.75" ID, 4" OD, VITON | 1 | FVB408 | < | < |
| 25 | C200 MASTER OIL SEAL HOUSING | 1 | FCM838 | < | < |
| 26 | OIL SEAL, 1-7/8 ID x 3-3/16 OD 1/4 THICK | 1 | FVB304 | < | < |
| 27 | OIL FILTER CARRIER | 1 | FCM835 | < | < |
| 28 | OIL FILTER NIPPLE | 1 | FCM845 | < | < |
| 29 | OIL FILTER, C200 SERIES | 1 | FVO201 | < | < |
| 30 | OIL FILTER MANIFOLD GASKET | 1 | FCM890 | < | < |
| 31 | PULLEY 1A X 4.7"PD / 7"PD FOR C260H | 1 | FVD241 | < | FVDA222 |
| 32 | V-BELT A37 | 1 | FVDA322 | < | FVD308 |
| 33 | BUSHING 1 3/8" BORE QD | 1 | FVDC205 | < | < |
| 34 | END PLATE | 1 | FCM829 | < | < |
| 35 | HHCS 1/2-13 X 1 3/4" GRADE 5 ZINC PLATED | 6 | FVH12PN1 | < | < |
| 36 | OIL SEAL 2.5" | 1 | FVB307 | < | < |
| 37 | BUSHING, QD TYPE F X 2-1/2 | 1 | FVD902 | < | < |
| 38 | FLYWHEEL, C200, 22 3/4P.D., 4 C SECTION | 1 | FCM825 | < | < |
| 39 | SIDE DOOR GASKET | 2 | FCM728 | < | < |
| 40 | SIDE DOOR BAFFLE | 1 | FCM796 | < | < |
| 41 | SIDE DOOR | 1 | FCM785 | < | < |
| 42 | HHCS 5/16-18 X 1-1/4 | 10 | FVH12HK1 | < | < |
| 43 | GASKET SIDE DOOR | 1 | FCM895 | < | < |
| 44 | SIDE DOOR | 1 | FCM881 | < | < |
| 45 | CAP BLACK | 1 | FPTA05AB | < | < |
| 46 | NIPPLE-BLACK 3/4 X 4" | 1 | FPTN0513AB | < | < |
| 47 | GAUGE-OIL SIGHT GLASS | 1 | FVO301 | < | < |
| 48 | SLOTTED FILLISTER, MACHINE SCREW, 10-32 X .625LG | 4 | FVH03CE | < | < |
| 49 | GASKET, OIL SIGHT CLASS, C200 | 1 | FCMA820 | < | < |
| 50 | CAP-PIPE-GALV. 1 1/4" | 1 | FPTA07AG | < | < |
| 51 | NIPPLE, 1-1/4NPT X 6 | 1 | FPTN0717AB | < | < |
| 52 | INTERCOOLER BKT, COMP END | 2 | FCMA853 | < | < |
| 53 | HHCS 1/2-13 X 1" GRADE 5 ZINC PLATED | 36 | FVH12PH1 | < | < |
| 54 | WASHER CUT 1/2" ZINC PLATED | 10 | FVH32P1 | < | < |
| 55 | INTERCOOLER SUPPORT BRACKET-INTERCOOLER SIDE | 2 | FCMA852 | < | < |
| 56 | SAE WASHER, PLAIN, 1/2" GR 2 | 20 | FVH33P | < | < |
| 57 | BREATHER VALVE (SIDE DOOR) | 1 | FCM664 | < | < |
| 58 | GASKET-BREATHER COVER | 1 | FCM665 | < | < |
| 59 | BREATHER COVER | 1 | FCM663 | < | < |
| 60 | SCREW-MACHINE 10/32 X 3/8 | 14 | FVH01CC | < | < |
| HP: FCMA888 x 1 | |||||
| 61 | CONNECTING ROD ASSY (LP AND HP) SEE NOTE 1 | 3 | FCM802 | < | LP: FCM802 x 2 |
| 62 | CONNECTING ROD BOLT C200 | 6 | FCM818 | < | < |
| 63 | CYLINDER HEAD STUD | 2 | FCM880 | < | < |
| 64 | WASHER-S A E 1/2" GR8 | 6 | FVH60P | < | < |
| 65 | NUT-FINISHED-HEX 1/2- 20UNF | 6 | FVH20N | < | < |
| 66 | CONNECTING ROD BEARING SEE NOTE 2 | 3 | FCM815 | < | < |
| 67 | ROLL PIN 3/8 DIA X 1 LG | 3 | FVH25MH | < | FVH25MF |
| 68 | L.P PISTON PIN, C200 / C300 SERIES | 2 | FCM820 | < | < |
| 69 | LP PISTON | 2 | FCM810 | < | < |
| 70 | C200 / C300 LP RING SET STD | 2 | FCMA810 | < | < |
| 71 | OIL STRAINER HOUSING | 1 | FCM846 | < | < |
| 72 | CYLINDER, L.P. | 2 | FCM822 | < | < |
| 73 | SCREW-HX. HEAD CAP 3/4 X 1 3/4" GRADE 2 | 12 | FVH11TN | < | < |
| 75 | OIL STRAINER COVER GASKET | 1 | FCM885 | < | < |
| 76 | LOW PRESSURE SUCTION ELBOW | 2 | FCM851 | < | < |
| 77 | CYLINDER HEAD ASSY, C200 / C300 SERIES | 3 | FCM805 | < | < |
| 78 | CYLINDER HEAD GASKET | 3 | FCM875 | < | < |
| 79 | CONNECTION-COMP. STRAIGHT SLEEVE AND NUT 1/8 X 1/4 | 4 | FVA14ACE | < | < |
| 80 | HEAD FLANGE GASKET | 9 | FCM734 | < | < |
| 81 | STRAINER-INLET FILTER 2 1/2" | 2 | FVA1145 | < | < |
| 82 | FILTER ELEMENT | 2 | FVA1144 | < | < |
| 83 | HHCS 5/8-11UNC X 1 3/4 | 24 | FVH12RN | < | < |
| 84 | CONNECTING ROD BUSHING | 6 | FCM817 | < | SEE NOTE 3 |
| 85 | C200 / C300 HP PISTON | 1 | FCM811 | < | FCMA877 |
| 86 | HP PISTON PIN C200, C260, C300 | 1 | FCM819 | < | FCMA878D |
| 87 | HP RING SET, C200 / C260 / C300 | 1 | FCMA809 | < | FCC1356 |
| 88 | HP CYLINDER, C200, C260, C300 | 1 | FCM821 | < | FCMA828 |
| 89 | HP DISCHARGE FLANGE | 1 | FCM882 | < | < |
| 90 | CYLINDER TO CRANKCASE GASKET | 3 | FCM729 | < | < |
| 91 | INTERCOOLER TUBE LEFT HAND | 1 | FCMA812 WELDED ASSY | ||
| 92 | ELBOW-COMPRESSION-WITH SLEEVE AND NUT 1/4 X 1/4 | 2 | FVA15BCE | < | < |
| 93 | INTERCOOLER TUBE RIGHT HAND | 1 | FCMA813 WELDED ASSY | ||
| 94 | HP SUCTION PIPE | 1 | FCM842 | < | < |
| 95 | HHCS 1/2-13UNC X 1 .5 | 14 | FVH12PM | < | < |
| 96 | INTERCOOLER FAN BRACKET | 1 | FCM852 | < | < |
| 97 | NUT-HEX-STEEL-LIGHT 1-14" | 1 | FVH1507 | < | < |
| 98 | LOCKWASHER 1 IN SPLIT LT | 1 | FVH37X | < | < |
| 99 | SAE WASHER 1" PLAIN | 2 | VH33X | < | < |
| 100 | LOCKWASHER LIGHT 1/2" ZINC PLATED | 2 | VH35P1 | < | < |
| 101 | HHCS,3/8-16 X 3-1/2" | 1 | CM879 | < | < |
| 102 | WASHER, FLAT 3/8" SAE | 31 | VH33K1 | < | 45 Qty |
| 103 | INTERCOOLER FAN SHAFT | 1 | FCM854 | < | < |
| 104 | KLOZURE-OIL SEAL 2" OD | 1 | FVB302 | < | < |
| 105 | SMALL END PLATE SHIM SET | 1 | FCMA685 | < | FCMA602 |
| 106 | INTERCOOLER FAN PULLEY | 1 | FCM855 | < | < |
| 107 | GREASE FITTING, 3/16" STRAIGHT | 1 | FVD701 | < | < |
| 108 | TAPERED ROLLER BEARING CUP AND CONE | 2 | FVD855 | < | < |
| 109 | SAE WASHER 3/4" | 1 | FVH33T | < | < |
| 110 | JAM NUT-NYLON INSER, 3/4-16 | 1 | FVH1527 | < | < |
| 111 | INTERCOOLER FAN PULLEY GASKET | 1 | FCM878 | < | < |
| 112 | INTERCOOLER FAN PULLEY COVERPLATE | 1 | FCM877 | < | < |
| 113 | C200 COMPRESSOR FAN | 1 | FCM724 | < | < |
| 114 | LOCK WASHER 5/16 SPLIT ZINC PLATED | 6 | VH35H1 | < | < |
ROTARY SCREW AIR COMPRESSORS
FOR AIR COMPRESSOR SERVICE
FOR AIR COMPRESSOR SALES
FOR AIR COMPRESSOR INSTALLATION
FOR AIR COMPRESSOR DRYERS
FOR AIR COMPRESSOR MAINTENANCE
CALL:
H&K PUMP @ 214-428-2868
| NO | DESCRIPTION | QTY | |||
| C200 | C260 | C260H | |||
| 115 | C200 TOP INTERCOOLER HEADER | 1 | FCM831 | < | < |
| 116 | NAMEPLATE - C200, C260 CAST IRON | 1 | FQAA276 | < | < |
| 117 | HHCS 5/16-18 X 1" GRADE 5 ZINC PLATED | 7 | FVH12HH1 | < | < |
| 118 | PLUG- SQUARE HEAD-STEEL 1/2" | 1 | FPTP04AB | < | < |
| 119 | ELBOW, 90 STREET 1NPT | 1 | FPTS06AB | < | < |
| 120 | POP VALVE, 1" NPT, 70PSI, 500CFM | 1 | FVV420 | < | FVV427 |
| 121 | C200 INTERCOOLER BOTTOM HEADER | 1 | FCM739 | < | < |
| 122 | DRAIN COCK 1/4" | 1 | FVV514 | < | < |
| 123 | INTERCOOLER SECTION GASKET | 8 | FCM735 | < | < |
| 124 | INTERCOOLER SECTION ASSY | 4 | FCMA704 | FCM803 | FCM803 |
| 125 | HHCS 1/2-13 X 1 1/4" GRADE 5 ZINC PLATED | 16 | FVH12PK1 | < | < |
| 126 | SHROUD ASSEMBLY LEFT HAND | 1 | FCM898LH | < | < |
| 127 | HHCS 3/8-16 X 1/2" GRADE 2 ZINC PLATED | 32 | FVH11KD1 | < | < |
| 128 | 3/8 USS FLAT WASHER | 2 | FVH32K1 | < | < |
| 129 | SHROUD ASSEMBLY RIGHT HAND | 1 | FCM898RH | < | < |
| 130 | FAN GUARD ASSY | 1 | FFCMA822 | < | < |
| 131 | SIDE FRAME, L H | 1 | CMA803 | < | < |
| 132 | FILLER ANGLE | 2 | FCMA805 | < | < |
| 133 | LOCKWASHER-#10 INTERNAL | 6 | FVH38D | < | < |
| 134 | APU AIR FILTER BRACKET | 1 | FVGB502 | < | < |
| 135 | APU AIR FILTER TOP | 1 | FVGB501 | < | < |
| 136 | APU AIR FILTER ELEMENT | 1 | FVGB501-E | < | < |
| 137 | FITTING COMPRESSION,1/4" MPT X 1/4" TUBE | 2 | FVA14BCE | < | < |
| 138 | R.H. SIDE FRAME INTERCOOLER | 1 | FCMA804 | < | < |
| 139 | INTERCOOLER TOP GUARD LH | 1 | FCMA802LH | < | < |
| 140 | INTERCOOLER TOP GUARD RH | 1 | FCMA802RH | < | < |
| 141 | GAUGE-OIL PRESSURE 2-1/2" 60 PSIG | 1 | FVA314 | < | < |
| 142 | OIL GAGE CONNECTOR | 1 | FCMA849 | < | < |
| 143 | TEE-COMPRESSION 1/4 X 1/4 X 4 | 1 | FVA729 | < | < |
| 144 | LOW OIL PRESSURE SWITCH4 | 1 | FVS502 | < | < |
| 145 | NUT FLARE TYPE COUPLING 1/4" | 1 | FVA701 | < | < |
| 146 | OIL STRAINER | 1 | FCM847 | < | < |
| 147 | O-RING, 1/16" X 1-1/8" ID VITON | 1 | FVB410 | < | < |
| 148 | OIL STRAINER COVERPLATE | 1 | FCM830 | < | < |
| 149 | OIL STRAINER SPRING | 1 | FCM896 | < | < |
| 150 | HHCS 5/16-18 X 3/4" GRADE 5 | 6 | FVH12HF1 | < | < |
| 151 | NUT HEX 5/8"-11 ZINC PLATED | 2 | VH15R1 | < | < |
WWW.HKAIRCOMPRESSORS.COM
| PART NUMBER | |||||
| ITEM | DESCRIPTION | QTY | |||
| NO | C200 | C260 | C260H | ||
| 1 | CYLINDER HEAD | 1 | FCM824 | < | < |
| 2 | VALVE SEAT GASKET | 2 | FCM874 | < | < |
| 3 | SUCTION VALVE ASSY | 1 | FCM887 | < | < |
| 4 | DISCHARGE VALVE ASSY | 1 | FCM888 | < | < |
| 5 | RETAINER-DISCHARGE VALVE | 1 | FCM858 | < | < |
| 6 | RETAINER-DISCHARGE VALVE | 1 | FCM859 | < | < |
| 7 | LP VALVE COVER PLATE GASKET | 2 | FCM657 | < | < |
| 8 | SUCTION VALVE COVER PLATE | 1 | FCM862 | < | < |
| 9 | DISCHARGE VALVE COVER PLATE | 1 | FCM863 | < | < |
| 10 | LOW PRESSURE UNLOADER PLUNGER | 1 | FCM869 | < | < |
| 11 | UNLOADER PISTON | 1 | FCM868 | < | < |
| 12 | UNLOADER CYLINDER | 1 | FCM867 | < | < |
| 13 | O-RING, 1/8", 1.25" ID | 1 | FVB409 | < | < |
| 14 | FLAT WASHER | 1 | FCM984 | < | < |
| 15 | PLUNGER RETURN SPRING | 1 | FCM872 | < | < |
| 16 | NUT 7/16-20NF-FLEX LOC | 1 | FVH20L | < | < |
| 17 | UNLOADER CYLINDER GASKET | 1 | FCM889 | < | < |
| 18 | UNLOADER CAP | 1 | FCM866 | < | < |
| 19 | UNLOADER PISTON RETURN SPRING | 1 | FCM871 | < | < |
| 20 | WASHER-ALUMINUM 9/16 X 25/64 X 0.051 | 8 | FVH1232 | < | < |
| 21 | NUT-STUD | 8 | FRK2063 | < | < |
| 22 | SCREW - SET HEX HEAD, CUP PT 3/8 X 1 3/4"LG | 8 | FVH08KN | < | < |
| 23 | HHCS 5/16-18 X 1" GRADE 5 ZINC PLATED | 4 | FVH12HH1 | < | < |
| 24 | HHCS 1/2-13UNC X 1 .5 | 8 | FVH12PM | < | < |
RETREADERS/ RECAPPERS/ REMOLDERS
COMPANIES THAT USE LARGE AIR COMPRESSORS
| Looneys Tire Service | Little Rock | AR | 72209 | 501-568-5218 | www.looneystirecenter.com | |
| Choices Tread Retreading | Casa Grande | AZ | 85122 | 602-722-8788 | tirescasagrande.com | |
| Redburn Tire Company | Phoenix | AZ | 85019 | 602-272-7601 | redburntireco.com | |
| Parkhouse Tire, Inc. | Bell Gardens | CA | 90201 | 562-928-0421 | parkhousetire.com | |
| TruckPro S.A. de C.V. | Calexico | CA | 92231 | 686-556-6583 | ||
| Miller Tire & Wheel | Carlsbad | CA | 92008 | 760-672-8473 | miller-tire.com | |
| Rovince Retread | Compton | CA | 90220 | 310-885-9797 | rovincetire.com/Home.aspx | |
| Petes Road Service, Inc. | Fullerton | CA | 92831 | 714-446-1207 | petesrs.com | |
| McCoy Truck Tire Service Center | Modesto | CA | 95351 | 209-521-6221 | ||
| Desser Tire and Rubber Company | Montebello | CA | 90640 | 323-721-4900 | desser.com | |
| New Pride Corporation | Oakland | CA | 94621 | 510-567-8800 | ||
| Lees Service | Reedley | CA | 93654 | 559-638-3535 | leesservice.com | |
| Daetweiler Tire Co. Inc. | South Gate | CA | 90280 | 310-537-7676 | ||
| Hunter Tires, Inc. | South Gate | CA | 90280 | 626-600-4676 | www.huntertires.com | |
| Brannon Tire Company | Stockton | CA | 95205 | 209-466-1881 | brannontire.com | |
| Tri-State Tire Company | Wallingford | CT | 6492 | 203-265-2027 | ||
| Fedan Tire Company | Hialeah | FL | 33010 | 305-885-5415 | ||
| Landrums Flotation Tires | Homestead | FL | 33031 | 305-248-8844 | landrums-tires.com | |
| McGee Tire | Lakeland | FL | 33801 | 863-559-1823 | www.mcgeetire.com | |
| MTC South, Inc. | Madison | FL | 32340 | (850) 251-5391 | mtcsouth.com | |
| Dimaggio Tires, Inc. | Miami Medley | FL | 33178 | 305-691-7297 | www.dimaggiotires.com | |
| Genius Tires Corporation | Pompano Beach | FL | 33064 | 954-317-1991 | www.geniustires4x4.com | |
| Quality Truck Treads | Claxton | GA | 30417 | 912-739-4614 | ||
| Columbus Tire Company | Columbus | GA | 31901 | www.columbustireco.com | ||
| Action Tire Company | Forest Park | GA | 30297 | 404-767-3235 | actiontireco.com | |
| Hill Tire Company | Forest Park | GA | 30297 | 404-361-6337 | hilltireco.com | |
| Dorsey Tire Company | Pooler | GA | 31322 | 912-964-6798 | dorseytire.com | |
| Smith Bros. Tire Service, Inc. | Sylvania | GA | 30467 | 912-863-4567 | www.sostire.com | |
| EBT ECO | Waipahu | HI | 96797 | 808-680-7634 | www.eastbaytire.com | |
| Davis County Tire | Bloomfield | IA | 52537 | 888-855-8740 | eitire.com | |
| Eastern Iowa Tire | Davenport | IA | 52806 | 800-292-1266/563-210-4286 | eitire.com | |
| Weldon Tire | Dubuque | IA | 52002 | 800-728-3991 | eitire.com | |
| JIREH INC. | Barry | IL | 62312 | 217-335-3276 | jirehinc.com | |
| Tredroc Tire Services | Elk Grove | IL | 60007 | 224-265-4070 | tredroc.com | |
| Brahlers Truckers Supply, Inc. | Jacksonville | IL | 62650 | 217-245-9062 | brahlers.com | |
| Commercial Tire Service, Inc. | Melrose Park | IL | 60160 | 708-345-3211 | commercialtireservices.com | |
| Morton Supplies, Inc. | Morton | IL | 61550 | 309-266-7173 | mortonsupplies.com | |
| Salem Tire Center, Inc. | Salem | IL | 62881 | 618-548-6645 | salemtirecenter.com | |
| Best-One Retreading of Indianapolis | Indianapolis | IN | 46236 | 317-895-6166 | www.bestonetire.com | |
| Best One Retreading of Princeton | Princeton | IN | 47670 | 812-386-6444 | tiredealersites.com/southernindiana | |
| Becker Tire & Treading, Inc. | Great Bend | KS | 67530 | 800-365-9791 | beckertire.com | |
| Heartland Tires and Treads of Kansas City, Inc | Kansas City | KS | 66115 | 877-281-4054 | heartlandtires.com | |
| BR Retreading Inc. | Glasgow | KY | 42141 | 270-651-5153 | brretreading.com | |
| Resley Tire Company Inc. | Hagerstown | MD | 21740 | 301-790-3941 | resleytire.com | |
| Purcell Tire & Rubber Company | Potosi | MO | 63664 | 573-438-2131 | purcelltire.com | |
| B&I Tire Company | Springfield | MO | 65807 | 417-882-5063 | www.bitire.com | |
| PRIME inc. | Springfield | MO | 65803 | 816-215-8628 | primeinc.com | |
| MFR Tire Service, Inc. | St Louis | MO | 63120 | 314-383-7300 | mfrtire.com | |
| Tucker Tire Service Inc. | St. Louis | MO | 63108 | 314-652-0715 | ||
| Southern Tire Mart | Columbia | MS | 39429 | 601-424-3200/214-631-7900 | www.stmtires.com | |
| RDH Tire & Retread Company | Cleveland | NC | 27013 | 704-278-9621 | rdhtire.com | |
| Colony Tire Corporation | Edenton | NC | 27932 | 252-482-5521 | colonytire.com | |
| Blacks Tire Service | Fayetteville | NC | 28306 | 910-484-4144 / 910- 642-4123 | blackstire.com | |
| BesTreads Inc. | Lewisville | NC | 27023 | 336-972-5944 | bestreadsinc.com | |
| Brays Recapping Service, Inc. | Mount Airy | NC | 27030 | 336-786-6182 | braystire.com | |
| Whites Tire Service | Wilson | NC | 27893 | 252-237-5429 | whitestireservice.com | |
| Garrett Tires & Treads | Grand Island | NE | 68802 | 308-382-0809 | garrett-tire.com | |
| Walker Tire Company | Lincoln | NE | 68514 | 402-476-3388 | walkertire.com | |
| Allied Retread Technologies | Omaha | NE | 68108 | 800-333-3717 | allied-oil.com | |
| Roli Retreads, Inc. | Farmingdale | NY | 11735 | 631-694-7670 | rolitire.com | |
| Treadware | Lake Katrine | NY | 12449 | 518-828-3020 | vankleecks.com | |
| Team Tiremasters | Odessa | NY | 14869 | 607-594-7106 | parmenterinc.com | |
| MDT Tire | Pelham Manor | NY | 10803 | 914-738-5126 | ||
| Canton Bandag Company | Canton | OH | 44706 | 330-454-3025 | cantonbandag.com | |
| Gem City Tire | Dayton | OH | 45413 | 937 890-8189 | gemcitytire.com | |
| Ziegler Tire | Massillon | OH | 44646 | 330-834-3332 | zieglertire.com | |
| H & H Industries | Oak Hill | OH | 45656 | 740-682-7721 | hhindustriesinc.com | |
| T & W Tire LLC | Oklahoma City | OK | 73148 | 405-495-0280 | www.tandwtire.com | |
| Superior Tire Service | Salem | OR | 97302 | 503-585-1955 | www.superiortireservice.com | |
| Ardmore Tire | Conshohocken | PA | 19428 | 610-834-1075 | ||
| Import Export Tire Company (Mr. Tire) | Latrobe | PA | 15650 | 724-539-8705 | ietires.com | |
| Mt. Morris Tire Service Inc. | Mt. Morris | PA | 15349 | 724-324-2200 | ||
| Sandone Tire | Scranton | PA | 18509 | 570-346-2004 | sandonetire.com | |
| Frasier Tire Service, Inc. | Sumter | SC | 29151 | 803-773-1423 | frasiertire.com | |
| Tire Recappers of Nashville Inc. | Nashville | TN | 37211 | 615-832-0887 | tirerecappers.com | |
| Border Recappng | El Paso | TX | 79936 | 575-652-9181 | www.borderrecapping.com | |
| Central Texas Retreading LLC | Elm Mott | TX | 76640 | 254-829-1379 | centraltexasretreading.com | |
| Treadwright | Houston | TX | 77011 | 877-439-0759 | treadwright.cotm | |
| Tube & Solid Tire LTD | San Antonio | TX | 78218 | 210-599-1222 | www.dobermann.org | |
| Pomps Tire Service Inc. | Green Bay | WI | 54305 | 920-435-8301 | pompstire.com | |
| Kings Tire Service | Bluefield | WV | 24701 | 304-325-3219 | kingtireservice.com |
USEFUL LINKS
| Casing Dealers | |
| Bob's Tire Company | http://www.bobstireco.com |
| Elite Tire International, Inc. | http://www.elitetire.com |
| Intyre | http://www.intyre.com |
| Kargro Group BV | http://www.kargro.com |
| Manley Tire | http://www.manleytiresales.com |
| Tire Bargain Center | http://www.tirebargaincenter.com |
| Tirecore International Ltd | http://www.tirecore.net |
| Environmental Organizations | |
| DK Enterprises | http://www.dkenterprises.us |
| LKQ Tire & Recycling, Inc. | http://www.lkqtire.com |
| Maryland Recyclers Coalition | http://www.mdrecycles.org |
| Recycling Research | http://www.scraptirenews.com |
| Tirecore International Ltd | http://www.tirecore.net |
| Miscellaneous Links | |
| Emerging Products Sales | http://www.emergingproductssales.com |
| Malerba Consulting, LLC | http://www.malerbas.com |
| Tire Guides Inc | http://www.tireguides.com |
| WECnology LLC | http://www.wecnology.com |
| Non-Destructive Testing Equipment For Retreaders | |
| Earthmover Tyres Scotland | http://www.earthmovertyresscotlandltd.com |
| Resources International Network Inc. | http://www.resources-international.net |
| TEI Service | http://www.teiworldwide.com |
| OTR Management & Retreading | |
| BR Retreading | http://www.brretreading.com |
| H&H Industries | http://www.hhindustriesinc.com |
| Rubber & Retreading Testing Services | |
| Akron Rubber Development Laboratory, Inc. (ARDL, INC) | http://www.ardl.com |
| Suppliers to the Retread and Tire Repair Industries | |
| Advantage ID, LLC | http://www.advantageid.com |
| AME International | http://www.ameintl.net |
| Fuller Brothers Inc. - Tire Life | http://www.fullerbros.com |
| Haltec | http://www.haltec.com |
| Hawkinson Companies | http://www.hawkinson.com |
| Monarch Vulcanising Systems Ltd | http://www.monaflex.com |
| Pelmar Engineering Ltd | http://www.pelmar.com |
| Pincott International Pty Ltd | http://www.pincott.com.au |
| Prema Canada ULC | http://www.premacanada.ca |
| Tuffy Manufacturing | http://www.tuffymfg.com |
| Tire/Wheel Balancing Systems | |
| Counteract Balancing Beads, Inc. | http://www.counteractbalancing.com |
| International Marketing, Inc. | http://www.imiproducts.com |
| Tire Lyna | http://www.tirelyna.com |
| Ultraseal International Inc. | http://www.ultraseal.com |
PISTON AIR COMPRESSORS
ROTARY SCREW AIR COMPRESSORS
FOR AIR COMPRESSOR SERVICE
FOR AIR COMPRESSOR SALES
FOR AIR COMPRESSOR INSTALLATION
FOR AIR COMPRESSOR DRYERS
FOR AIR COMPRESSOR MAINTENANCE
CALL:
H&K PUMP @ 214-428-2868
THE TOP RATED AIR
COMPRESSORS
FOR AIR COMPRESSOR MOTORS
FOR AIR COMPRESSOR PUMPS
FOR ROTARY SCREW COMPRESSORS
FOR PISTON COMPRESSORS
214-428-2868
AIR COMPRESSOR PARTS
AIR COMPRESSOR PISTONS
AIR COMPRESSOR FILTERS
AIR COMPRESSOR OIL
AIR COMPRESSOR BELTS
AIR COMPRESSOR RODS
AIR COMPRESSOR PRESSURE SWITCHES
AIR COMPRESSOR MAG STARTERS
AIR COMPRESSOR CONTACTORS
AIR COMPRESSOR OIL FILTERS
AIR COMPRESSOR VALVES
AIR COMPRESSOR CHECK VALVES
AIR COMPRESSOR GASKETS
AIR COMPRESSOR BEARINGS
CW300 SERIES
| NO. | REQ’D. | ||
| CW300 | VH01CC | 6 | RHMS, 10-32 x 3/8Lg. |
| CW300 | CM663 | 1 | Breather Cover |
| CW300 | CM664 | 1 | Breather Valve |
| CW300 | CM665 | 1 | Breather Cover Gasket |
| CW300 | CM729 | 6 | Cylinder Gasket |
| CW300 | CM821 | 2 | H.P. Cylinder |
| CW300 | CM822 | 4 | L.P. Cylinder |
| CW300 | CM830 | 1 | Oil Strainer Cover |
| CW300 | CM833 | 1 | Bearing Plate Cover |
| CW300 | CM834 | 1 | Flanged Bearing |
| CW300 | CM835 | 1 | Oil Filter Carrier |
| CW300 | CM836 | 1 | Bearing Plate |
| CW300 | CM845 | 1 | Oil Filter Nipple |
| CW300 | CM880 | 4 | Studs, 5/8 x 2 ¾” |
| CW300 | CM884 | 1 | Lube Pump Carrier Gear Key |
| CW300 | CM885 | 1 | Oil Strainer Cover Gasket |
| CW300 | CM886 | 1 | Master Oil Seal Gasket |
| CW300 | CM890 | 1 | Oil Filter Carrier Gasket |
| CW300 | CM893 | 1 | Bearing Plate Cover Gasket |
| CW300 | CM894 | 1 | Bearing Plate Gasket |
| CW300 | CM896 | 1 | Oil Strainer Spring |
| CW300 | CM912 | 1 | Crankcase |
| CW300 | CM913 | 1 | Endplate |
| CW300 | CM914 | 3 | Side Door |
| CW300 | CM915 | 1 | Side Door & Breather |
| CW300 | CM916 | 5 | Side Door Gasket |
| CW300 | CM917 | 1 | Side Door Baffle |
| CW300 | CM922 | 1 | Key-3/4 x ¾ x 4-1/4”Lg. |
| CW300 | CM923 | 1 | Lube Pump Carrier Gear |
| CW300 | CM924 | 1 | Closure Screw |
| CW300 | CM925 | 1 | Flywheel |
| CW300 | CM938 | 1 | Oil Strainer Housing |
| CW300 | CM939 | 1 | Oil Strainer |
| CW300 | CM943 | 1 | Shim Set |
| CW300 | CM965 | 1 | Gasket Set |
| CW300 | CM966 | 1 | Tubing Gauge to Filter |
| CW300 | CM967 | 1 | “O” Ring Set |
| CW300 | CMA815 | 1 | Tubing-Gauge to Switch |
| CW300 | CMA816 | 1 | Key ¼ x 5/16 x 1-1/4” Lg. |
| CW300 | VH12HH | 4 | HHCS, 5/16-18 x 1” (H.T.) |
| CW300 | VH35R | 3 | Lockwasher - Split 5/8 |
| CW300 | VH15R | 4 | Hex Nut, 5/8-11 |
| CW300 | VA729 | 1 | Brass Tee, ¼ MPT x ¼ FPT x ¼ |
| CW300 | VH12RY | 3 | HHCS, 5/8 UNC x 4 ½” Lg. |
| CW300 | VH11TN | 24 | HHCS, ¾-10 x 1 3/4 |
| CW300 | CM810 | 4 | Piston L.P. Std. |
| CW300 | CM810-010 | 4 | Piston .010 Undersized |
| CW300 | CM810-030 | 4 | Piston .030 Undersized |
| CW300 | CMA811 | 2 | Piston H.P. Std. |
| CW300 | CMA811-010 | 2 | Piston .010 Undersized |
| CW300 | CMA811-030 | 2 | Piston .030 Oversized |
| CW300 | CM8190 | 2 | Piston Pin H.P. |
| CW300 | CM820 | 4 | Piston Pin L.P. |
| CW300 | VH25MH | 6 | Piston Pin Spring Pin |
| CW300 | CMA809 | 2 | Piston Ring Set - HP Std. |
| CW300 | CMA809-010 | 2 | Piston Ring Set - HP .010 Oversized |
| CW300 | CMA809-030 | 2 | Piston Ring Set - HP .030 Oversized |
| CW300 | CMA810 | 4 | Piston Ring Set - LP Std. |
| CW300 | CMA810-010 | 4 | Piston Ring Set - LP .010 Oversized |
| CW300 | CMA810-030 | 4 | Piston Ring Set - LP .030 Oversized |
| CW300 | CM841 | 1 | Lube Pump Drive Gear |
| CW300 | CM891 | 1 | Lube Pump Drive Gear Key |
| CW300 | CM910 | 1 | Crankshaft |
| CW300 | CM910A | 1 | Crankshaft w/RB Cones VD802 & 804 |
| CW300 | VAA857 | 2 | Crankshaft Endplug |
| CW300 | VD802 | 1 | Roller Brg. Cup JH211710 |
| CW300 | VD803 | 1 | Roller Brg. Cone JH211749 |
| CW300 | VD804 | 1 | Roller Brg. Cup JH217210 |
| CW300 | VD805 | 1 | Roller Brg. Cone JH217249 |
| CW300 | VH1410 | 1 | Set Scr 5/16”-18 x 3/8”Lg. Self Locking |
| CW300 | VA01BA | 5 | ¼ MPT Pipe Plug |
| CW300 | VA1132 | 2 | Air Filter |
| CW300 | VA1133 | 2 | Air Filter Elements |
| CW300 | VA13BBC | 1 | Unloader Pilot Nipple Short ¼” X-Heavy |
| CW300 | VB409 | 6 | “O” Ring 1 ¼ x 1 ½ x 1/8 Viton |
| CW300 | VH09KN | 48 | Set Screw - 3/8 NC-1 ¾” Lg. |
| CW300 | VH12RN | 48 | HHCS, 5/8-11 x 1 ¾ (HT) |
| CW300 | VH12PM | 48 | HHCS, ½-13 UNC x 1 ½ (HT) |
| CW300 | VV1003 | 1 | Unloader Pilot |
| CW300 | VH01CC | 6 | RHMS, #10-32 x 3/8” |
| CW300 | CM734 | 4 | Small 4 Bolt Flange Gasket |
| CW300 | CM735 | 10 | Intercooler Section Gasket |
| CW300 | CMA856 | 2 | Intercooler Support Bracket - |
| CW300 | CM909 | 5 | Intercooler Section Assembly |
| CW300 | CM918 | 5 | Intercooler Section Top Header |
| CW300 | CM919 | 5 | Intercooler Section Bottom Header |
| CW300 | CM920 | 10 | Intercooler Section Header Plate |
| CW300 | CM921 | 10 | Intercooler Section Side Frame |
| CW300 | CM926 | 1 | Intercooler Top Header |
| CW300 | CM927 | 1 | Intercooler Bottom Header |
| CW300 | CM928 | 2 | Manifold Tee Connection |
| CW300 | CM929 | 1 | High Pressure Flange Connection |
| CW300 | CM930 | 1 | High Pressure Suction Elbow |
| CW300 | CM932 | 4 | Low Pressure Discharge Elbow |
| CW300 | CM933 | 2 | Low Pressure Discharge Flange |
| CW300 | CM934 | 2 | Intercooler Support Bracket - |
| CW300 | CM935 | 1 | R.H. Side Frame |
| CW300 | CM936 | 1 | L.H. Side Frame |
| CW300 | CM937 L.H. | 1 | L.H. Fan Shroud |
| CW300 | CM937 R.H. | 1 | R.H. Fan Shroud |
| CW300 | CM979 | 1 | Discharge Manifold Connection |
| CW300 | CM941 | 5 | Large 4 Bolt Flange Gasket |
| CW300 | CM982 | 1 | Discharge Flange Gasket |
| CW300 | CM944 | 2 | Discharge Elbow - 1st Stage |
| CW300 | CM945 | 45 | Intercooler Tube |
| CW300 | VH03CE | 4 | FHMS, 10-32 x 5/8 |
| CW300 | VA13EGC | 1 | Pipe Nipple x Heavy ¾” x 4” Lg |
| CW300 | VA314 | 1 | Oil Pressure Gauge |
| CW300 | VA14ACE | 1 | Brass Conn. ¼ MDT x ¼ Tube |
| CW300 | VA14BCE | 1 | Brass Elbow ¼ FPT x ¼ Tube |
| CW300 | VA13GLB | 1 | Pipe Nipple, 1 ¼” x 6” Lg. |
| CW300 | VA04GO | 1 | Pipe Cap, 1 ¼” |
| CW300 | VA04EP | 1 | Pipe Cap, ¾” |
| CW300 | VB306 | 1 | Oil Seal |
| CW300 | VB410 | 1 | “O” Ring, 1 1/8 x 1 ¼ x 1/16 |
| CW300 | VDA222 | 1 | Sheave, Complete w/Hardware |
| CW300 | VD802 | 1 | Roller Brg. Cup, JH 211 710 |
| CW300 | VD804 | 1 | Roller Brg. Cup, JH 211 210 |
| CW300 | VD903 | 1 | Bushing w/ Hardware |
| CW300 | VH1312 | 1 | Spring Pin, 1/4Ø x 11/16 Lg. |
| CW300 | VH1414 | 1 | Set Scr. Cup Pt, 3/8 NF x ½” |
| CW300 | VH12KH | 3 | HHCS, 3/8-16 x 1” (H.T.) |
| CW300 | VH12PT | 8 | HHCS, ½-13 x 3” (H.T.) |
| CW300 | VH12PN | 6 | HHCS, ½-13 x 1 ¾” (H.T.) |
| CW300 | VH13ED | 3 | RHMS, 6/32 x 3/8 |
| CW300 | CM981 | 1 | Oil Pump |
| CW300 | VO103 | 1 | Oil Pump Retaining Spring |
| CW300 | VO201 | 1 | Oil Filter |
| CW300 | VO301 | 1 | Oil Sight Glass |
| CW300 | VH12HK | 16 | HHCS, 5/16-18 x 1 ¼ (H.T.) |
| CW300 | VS502 | 1 | Oil Pressure Switch |
| CW300 | CM802 | 6 | Connecting Rod Complete |
| CW300 | CM802-001 | 6 | Connecting Rod .001 Undersized |
| CW300 | CM815 | 6 | Bearing Set |
| CW300 | CM816-001 | 6 | Bearing Set, .001 Undersized |
| CW300 | CM817 | 12 | Pin Bushing |
| CW300 | CM818 | 12 | Connecting Rod Bolt |
| CW300 | VH33P | 12 | Washer - Cut ½” SAE |
| CW300 | VH20N | 12 | Locknut - ½-20 |
| CW300 | CM657 | 12 | Cover Plate Gasket |
| CW300 | CM734 | 12 | 4 Bolt Flange Gasket |
| CW300 | CM805 | 6 | Cylinder Head Assembly |
| CW300 | CM824 | 6 | Cylinder Head |
| CW300 | CM858 | 6 | Suction Valve Retainer |
| CW300 | CM859 | 6 | Discharge Valve Retainer |
| CW300 | CM862 | 6 | Suction Valve Cover Plate |
| CW300 | CM863 | 6 | Discharge Valve Cover Plate |
| CW300 | CM866 | 6 | Unloader Cap |
| CW300 | CM867 | 6 | Unloader Cylinder |
| CW300 | CM868 | 6 | Unloader Piston |
| CW300 | CM869 | 6 | Unloader Plunger |
| CW300 | CM871 | 6 | Piston Return Spring |
| CW300 | CM872 | 6 | Plunger Return Spring |
| CW300 | CM874 | 12 | Valve Gasket (Alum.) |
| CW300 | CM880 | 4 | Stud 5/8-11 x 2 ¾” Lg. |
| CW300 | CM887 | 6 | Suction Valve w/ Unloader |
| CW300 | CM887-1 | 6 | Unloader Fork Locknut |
| CW300 | CM887-2 | 6 | Unloader Fork |
| CW300 | CM887-3 | 6 | Unloader Fork Spring |
| CW300 | CM887-4 | 12 | Centerbolt Locknut |
| CW300 | CM887-5 | 6 | Valve Seat |
| CW300 | CM887-6 | 12 | Washer (Thick) |
| CW300 | CM887-7 | 12 | Valve Plate |
| CW300 | CM887-8 | 12 | Dampening Plate |
| CW300 | CM887-9 | 12 | Spring Plate |
| CW300 | CM887-10 | 12 | Washer (Thin) |
| CW300 | CM887-11 | 6 | Guard Plate |
| CW300 | CM887-12 | 6 | Centerbolt |
| CW300 | CM888 | 6 | Discharge Valve |
| CW300 | CM888-1 | 6 | Locknut Washer |
| CW300 | CM888-2 | 6 | Guard Plate |
| CW300 | CM888-3 | 12 | Spring Plate |
| CW300 | CM888-4 | 6 | Valve Seat |
| CW300 | CM875 | 6 | Cylinder Head Gasket |
| CW300 | CM889 | 6 | Unloader Cylinder Gasket |
| CW300 | CM931 | 2 | Suction Manifold |
| CW300 | CM941 | 4 | Large 4 Bolt Flange Gasket |
| CW300 | CM962 | 3 | Unloader Tubing (Cyl. To Cyl.) |
| CW300 | CM963 | 1 | L.H. Unloader Tubing (Bank to Bank) |
| CW300 | CM964 | 1 | R.H. Unloader Tubing (Bank to Bank) |
| CW300 | VH12HH | 24 | HHCS 5/16-18 x 1 (H.T.) |
| CW300 | VH12PM | 16 | HHCS ½-13 x 1” |
| CW300 | VH20L | 6 | Locknut, 7/16”-20 |
| CW300 | VH32MOB | 6 | Washer, 7/16 I.D. - 1 ¼” O.D. x 14 Ga. |
| CW300 | RK206-3 | 48 | Stud Nuts |
| CW300 | VH1225 | 48 | Washer, 25/64 I.D. x 9/16 O.D. x .051 |
| CW300 | VA14ACE | 10 | ¼ MPT x ¼ Tube Conn. |
| CW300 | VA01AA | 5 | 1/8 Pipe Plug |
| CW300 | CM946 | 4 | Intercooler Blank Flange |
| CW300 | CM948 | 1 | Bottom Fan Shroud |
| CW300 | CM949 | 1 | Top Fan Shroud |
| CW300 | CM950 | 1 | Air Baffle |
| CW300 | CM951 | 2 | Filler Angle |
| CW300 | CM952 | 2 | High Side Manifold Pipe |
| CW300 | CM955 | 1 | High Pressure Suction Manifold Assy. |
| CW300 | CM956 | 1 | L.H. Low Pressure Discharge Tube - 2nd |
| CW300 | CM957 | 1 | R.H. Low Pressure Discharge Tube - 2nd |
| CW300 | CM958 | 2 | L.P. Discharge Connection |
| CW300 | CM959 | 2 | Discharge Tube Reducer |
| CW300 | CM960 | 1 | L.H. Low Pressure Discharge Manifold |
| CW300 | CM961 | 1 | R.H. Low Pressure Discharge Manifold |
| CW300 | CM922 | 1 | Discharge Manifold Assembly |
| CW300 | VH32P | 10 | Washers ½” Cut |
| CW300 | VH38F | 80 | Lockwashers ¼” (shakeproof) |
| CW300 | VH35P | 12 | Lockwashers ½” Split |
| CW300 | VH11KD | 24 | HHCS, 3/8-16 x ½” |
| CW300 | VH11TP | 16 | HHCS, 3/4-10 x 2” |
| CW300 | VH35T | 16 | Lockwasher - ¾” Split |
| CW300 | VH12PM | 12 | HHCS, ½-13 x 1” |
| CW300 | VH12FE | 80 | HHCS, ¼-20 x 5/8” |
| CW300 | VA1402 | 1 | High Pressure Discharge Flange, 4”-150# |
| CW300 | VB404 | 90 | “O” Rings 1” O.D. x ¾” I.D., Viton |
| CW300 | VH33K | 24 | Washer SAE 3/8 |
| CW300 | VH33P | 20 | Washer SAE ½ |
| CW300 | VH12PK | 52 | HHCS, ½-13 x 1 ¼” |
| CW300 | VH12TS | 16 | HHCS, ¾-10 x 2 ¾” (H.T.) |
| CW300 | VH38D | 6 | Lockwasher #10 |
| CW300 | VH15T | 16 | Hex Nut ¾” - 10 |
| CW300 | VV421 | 1 | Safety Pop Valve 1 ¼” ASME Set 70# |
| CW300 | VV514 | 1 | Drain Cock ¼” |
| NO. | REQ’D. | DESCRIPTION | |
| CW100 | VH-01CC | 4 | Round Head Machine Screw, #10-32 x 3/8” |
| CW100 | CM-663 | 1 | Breather Cover (41753 thru 41969, C-10001 & Later) |
| CW100 | CM-664 | 1 | Breather Valve |
| CW100 | CM-665 | 1 | Gasket (Breather Cover)(41753 thru 41969, C-10001 & Later) |
| CW100 | CM-701 | 1 | Crankcase with Oil Cup |
| CW100 | CM-702 | 2 | Low Pressure Cylinder |
| CW100 | CM-703 | 1 | High Pressure Cylinder |
| CW100 | CM-711 | 1 | Large End Plate with Cup #r-641 |
| CW100 | CM-712 | 1 | Side Door w/Breather Port**Furnish(1) CM-785,(2) CM-728, (1) |
| CW100 | CM-713 | 1 | Side Door with Oil Filler Port |
| CW100 | CM-714 | 1 | Flywheel, 24-1/2” |
| CW100 | CM-716 | 1 | Fan Hub |
| CW100 | CM-717 | 1 | Oil Gauge |
| CW100 | CM-718 | 18 | Cylinder Head Stud, ¾” x 3” |
| CW100 | CM-719 | 1 | Side Door Baffle with Shield(41418 thru 41752) |
| CW100 | CM-727 | 1 | Side Door Gasket(Breather)(41418 thru 41752) |
| CW100 | CM-728 | 3 | Side Door Gasket |
| CW100 | CM-729 | 3 | Crankcase Gasket |
| CW100 | CM-730 | 3 | Cylinder Head Gasket |
| CW100 | CM-731 | 1 | Large End Plate Gasket |
| CW100 | CM-732 | 2 | Small End Plate Gasket |
| CW100 | CM-736 | 2 | Small End Plate |
| CW100 | CMA-724 | 1 | 23-1/2” Dia. - 6 Blade Fan |
| CW100 | CM-744 | 1 | Oiling Ring |
| CW100 | CM-745 | 1 | Oiling Ring Hold Down Pin |
| CW100 | CM-750 | 1 | Oil Ring Retainer (41418 thru 41523) |
| CW100 | CM-764 | 1 | Oil Diverter Assy (Furnish Instructions CM-771)(41524 thru |
| CW100 | CM-772 | 1 | Gasket Set |
| CW100 | CM-773 | 1 | Oil Ring Retainer (41662 thru 41969,C-10001 & Later) |
| CW100 | CM-785 | 1 | Side Door with Breather Port |
| CW100 | CM-786 | 1 | Side Door Baffle **Furnish CM-796(41753 thru 41929) |
| CW100 | CM-792 | 1 | Shim Set |
| CW100 | CM-796 | 1 | Side Door Baffle (41753 thru 41969, C-10001 & Later) |
| CW100 | CMA-714 | 2 | Spacer (Oil Ring Retainer)(C-10012 & Later) |
| CW100 | CX-3-M | 1 | Flywheel Key, 5/8” Square x 5 1/8” Lg. |
| CW100 | CX-9-AJ | 1 | Flywheel Lockwasher |
| CW100 | CX-9-BC | 1 | Hex Half Nut, 1 ¾”-NF (Flywheel) |
| CW100 | VH-35H | 6 | Kantlink Lockwasher, 5/16” (Fan) |
| CW100 | VH-01FD | 7 | Button Head mach. Scr. ¼”-NC x ½” (41418 thru 41752) |
| CW100 | VH-11HF | 6 | Hex Head Cap Screw, 5/16””NC x ¾” (Fan) |
| CW100 | VH-35F | 7 | Kantlink Lockwasher, 1/4” |
| CW100 | VH-11FF | 2 | Hex Head Cap Screw, 1/4”NC x 3/4” (Oil Ring Retainer)(C- |
| CW100 | VH-38F | 2 | Shakeproof Lockwasher, ¼” |
| CW100 | VH-35P | 2 | Kantlink Lockwasher, 1/2” |
| CW100 | VH-12PK | 8 | Hex Head Cap Screw, 1/2”NC x 1 1/4” |
| CW100 | VH-16Z | 1 | Hex Half Nut, 1-1/4”NC (Fan) |
| CW100 | VA-01EA | 1 | Pipe Plug, ¾” |
| CW100 | VH-11FD | 2 | Hex Head Cap Screw, 1/4”NC x ½” (C-10011A & Earlier) |
| CW100 | VH-11TN | 12 | Hex Head Cap Screw, ¾”NC x 1 ¾” |
| CW100 | VB-310 | 1 | Garlock Closure (Flywheel End) |
| CW100 | VB-307 | 1 | Garlock Closure (Fan End) |
| CW100 | VA-15DGE | 1 | Copper Tube Elbow, ½”MPT x 5/8” Tube |
| CW100 | VA-14DGE | 1 | Copper Tube Connector, ½”MPT x 5/8” Tube |
| CW100 | VH-11PD | 2 | Hex Head Cap Screw, ½”NC x ½” (Oil Diverter) |
| CW100 | VA-13JEA | 2 | Pipe Nipple, 2”IPT x 3” Lg. |
| CW100 | VA-06JF | 2 | 90° Pipe Elbow, 2” IPT |
| CW100 | VA-1128 | 2 | Filter Silencer, 2” |
| CW100 | VH-11HK | 12 | Hex Head Cap Screw, 5/16”NC x 1 ¼” |
| CW100 | VH-38D | 2 | Shakeproof Lockwasher, #10 (Breather Valve) |
| CW100 | VH-1106 | 1 | Woodruff Key #15 (Fan) |
| CW100 | VH-15T | 18 | Hex Nut, ¾” NC (Cyl. Head) |
| CW100 | VH-37Z | 1 | Kantlink Lockwasher, 1 ¼” (Fan) |
| CW100 | VH-11PM | 8 | Hex Head Cap Screw, ½”NC x 1 ½” |
| CW100 | VA-1129 | 2 | Filter Element |
| CW100 | CM-722 | 2 | Intercooler Support **Furnish (1) CM-797, (2) CM-798, |
| CW100 | CM-723 | 2 | Discharge Flange - LP Head **Furnish CM-799 LH |
| CW100 | CM-724 | 1 | LH Intercooler Shroud Frame |
| CW100 | CM-725 | 1 | RH Intercooler Shroud Frame |
| CW100 | CM-733 | 4 | Flange Gasket |
| CW100 | CM-734 | 2 | Intercooler Inlet Gasket |
| CW100 | CM-735 | 8 | Intercooler Section Gasket |
| CW100 | CM-738 | 1 | Intercooler Top Header |
| CW100 | CM-739 | 1 | Intercooler Bottom Header |
| CW100 | CM-747 | 4 | Intercooler Section **Furnish CMA-713 |
| CW100 | CM-748 | 1 | Intercooler Bottom Shroud Plate |
| CW100 | CM-749 | 1 | Intercooler Top Shroud Plate |
| CW100 | CM-751 | 1 | HP Suction Elbow |
| CW100 | CM-752 | 2 | Intercooler Inlet Elbow **Furnish CM-799 LH |
| CW100 | CM-753 | 1 | LH Intercooler Tube **Furnish CMA-799 |
| CW100 | CM-754 | 1 | RH Intercooler Tube **Furnish CMA-700 |
| CW100 | CM-797 | 2 | Intercooler Support Bracket (41919 thru 41969, C- |
| CW100 | CM-798 | 2 | Intercooler Support Bracket, Compressor Side (41919 |
| CW100 | CM-799 | 1 | LH Intercooler Tube Assembly |
| CW100 | CMA-700 | 1 | RH Intercooler Tube Assembly |
| CW100 | CMA-705-A | 24 | Intercooler Tube (C-10009 & Later) |
| CW100 | CMA-706 | 8 | Header Plate (C-10009 & Later) |
| CW100 | CMA-707 | 4 | Top Header (Intercooler Section)(C-10009 & Later) |
| CW100 | CMA-708 | 4 | Bottom Header (Intercooler Section)(C-10009 & Later) |
| CW100 | CMA-709 | 8 | Side Frame (Intercooler Section)(C-10009 & Later) |
| CW100 | CMA-713 | 4 | Intercooler Section Assembly (Kit) |
| CW100 | VH-32P | 2 | Cut Washer, ½” (41919 thru 41969, C-10001 & Later) |
| CW100 | CH-38F | 48 | Shakeproof Lockwasher, ¼” (C-10009 & Later) |
| CW100 | VH-35P | 8 | Kantlink Lockwasher, ½” |
| CW100 | VH-12PK | 16 | Hex Head Cap Screw, 1/2” NC x 1 1/4” |
| CW100 | VH-15P | 2 | Hex Nut, ½”NC (41919 thru 41969, C-10001 & Later) |
| CW100 | VV-513 | 1 | Weatherhead Drain Cock, 1/8” |
| CW100 | VH-11KD | 24 | Hex Head Cap Screw, 3/8” NC x ½” |
| CW100 | VH-11RM | 16 | Hex Head Cap Screw, 5/8” NC x 1 ½” |
| CW100 | VA-01GA | 2 | Pipe Plug, 1 ¼” |
| CW100 | VH-11PH | 16 | Hex Head Cap Screw, ½”NC x 1” |
| CW100 | VH-12FE | 12 | Hex Head Cap Screw, ¼”NC x 5/8”HT (C-10009 & Later) |
| CW100 | VB-404 | 48 | O-Ring #17107A (C-10009 & Later) |
| CW100 | VH-11PM | 2 | Hex Head Cap Screw, ½”NC x 1 ½ |
| CW100 | VV-407 | 1 | Pop Valve, Knuckle, ½” NPT - 70# |
| CW100 | VH-12FD | 4 | Hex Head Cap Screw, ¼-20 x ½” |
| CW100 | CM-708 | 3 | Connecting Rod**Furnish CM-760 |
| CW100 | CM-742 | 6 | Connecting Rod Bushing (kit) |
| CW100 | CM-743 | 3 | Connecting Rod Bearing Set |
| CW100 | CM-746 | 6 | Connecting Rod Bolts, 5/8-18 x 4 ¾” |
| CW100 | CM-760 | 3 | Connecting Rod with Bushing & Bearing |
| CW100 | VH-18Q | 6 | Castel Nut, 5/8” NF |
| CW100 | VH-23DM | 6 | Cotter Pin, 1/8” x 1 ½” |
| CW100 | CM-778 | 3 | Connectiing Rod Bearing Set, Oversize for .001 |
| CW100 | CM-629 | 2 | Piston - LP Standard |
| CW100 | CM-629-010 | 2 | Piston - LP .010 Oversize |
| CW100 | CM-629-030 | 2 | Piston - LP .030 Oversize |
| CW100 | CM-644 | 2 | Piston Pin - LP |
| CW100 | CM-645 | 2 | Piston Pin Lock Screw - LP |
| CW100 | CM-646 | 2 | Lockwasher (Piston Pin) - LP |
| CW100 | CM-687 | 2 | Piston with Rings & Pin - LP Standard |
| CW100 | CM-687-010 | 2 | Piston with Rings & Pin - LP .010 Oversize |
| CW100 | CM-687-030 | 2 | Piston with Rings & Pin - LP .030 Oversize |
| CW100 | CMA-720 | 1 | Piston - HP Standard |
| CW100 | CMA-720-010 | 1 | Piston - HP .010 Oversize |
| CW100 | CMA-720-030 | 1 | Piston - HP .030 Oversize |
| CW100 | CM-715 | 1 | Piston Pin - HP |
| CW100 | CM-789 | 1 | Piston with Rings & Pin - HP Standard |
| CW100 | CM-789-010 | 1 | Piston with Rings & Pin - HP .010 Oversize |
| CW100 | CM-789-030 | 1 | Piston with Rings & Pin - HP .030 Oversize |
| CW100 | CMA-701 | 1 | Piston with Pin, Rings Rod & Bearings - HP |
| CW100 | CMA-702 | 2 | Piston with Pin, Rings Rod & Bearings - LP |
| CW100 | VH-23HT | 1 | Cotter Pin, ¼” x 3” (HP Piston) |
| CW100 | VD-1106 | 1 | Woodruff Key, #15 (HP Piston) |
| CW100 | CM-790 | 2 | Piston Ring Set - LP Standard |
| CW100 | CM-790-010 | 2 | Piston Ring Set - LP .010 Oversize |
| CW100 | CM-790-030 | 2 | Piston Ring Set - LP .030 Oversize |
| CW100 | CM-791 | 1 | Piston Ring Set - HP Standard |
| CW100 | CM-791-010 | 1 | Piston Ring Set - HP .010 Oversize |
| CW100 | CM-791-030 | 1 | Piston Ring Set - HP .030 Oversize |
| CW100 | CMA-719 | 1 | Crankshaft with Oil Cup |
| CW100 | CM-710 | 2 | Counterweight |
| CW100 | CM-746 | 4 | Counterweight Bolt, 5/8”NF x 4 ¾” |
| CW100 | CX-9-K | 4 | Counterweight Sleeve |
| CW100 | VH-08FF | 4 | Hex Hollow Head CP Set Screw, ¼”NC x ¾ |
| CW100 | VD-826 | 1 | Roller Bearing Cone - 39585 - Fan End |
| CW100 | VD-827 | 1 | Roller Bearing Cone - 566 - Flywheel End |
| CW100 | VD-824 | 1 | Roller Bearing Cup - 39520 - Fan End |
| CW100 | VD-828 | 1 | Roller Bearing Cup - Flywheel End |
| CW100 | CA-299-46 | 21 | Suction Valve Spring-LP & HP (also used for |
| CW100 | CM-623 | 3 | Suction Valve Cover Plate - LP & HP |
| CW100 | CM-625 | 3 | Discharge Valve cover Plate - LP & HP |
| CW100 | CM-627 | 3 | Spacer - LP |
| CW100 | CM-633 | 3 | Discharge Valve Backstop Kit - LP (41418 thru 41969, |
| CW100 | CM-636 | 3 | Suction Valve Seat - LP & HP |
| CW100 | CM-640 | 6 | Valve Disc - LP & HP |
| CW100 | CM-641 | 6 | Valve Disc - LP & HP |
| CW100 | CM-657 | 6 | Valve Cover Plate Gasket - LP & HP |
| CW100 | CM-697 | 3 | Discharge Valve Seat with Stud |
| CW100 | CM-699 | 3 | Suction Valve Backstop with Stud |
| CW100 | CM-704 | 2 | Cylinder Head - LP for 41418 thru 41739, Breather |
| CW100 | CM-740 | 1 | Cylinder Head - HP |
| CW100 | CM-761 | 3 | Suction Valve Assembly - LP & HP |
| CW100 | CM-762 | 3 | Discharge Valve Assembly - LP & HP |
| CW100 | CM-794 | 2 | Cylinder Head Assembly with Gasket - LP |
| CW100 | CM-795 | 1 | Cylinder Head Assembly with Gasket - HP |
| CW100 | CMA-642 | 3 | Discharge Valve Backstop - LP & HP (C-10010 & Later) |
| CW100 | CMA-646 | 42 | Valve Spring Button - LP & HP (C-10010 & Later) |
| CW100 | CMA-647 | 21 | Discharge Valve Spring - LP & HP (C-10010 & Later) |
| CW100 | VH-23CF | 6 | Cotter Pin, 3/32” x ¾” |
| CW100 | RK-2-9-E | 24 | Stud Nut |
| CW100 | VH-1225 | 24 | Solid Copper Washer, 25/64” x 9/16” x .051 |
| CW100 | VH-1403 | 24 | Hex Hollow Hd. Flat Point Set Screw, 3/8”NC x 2” |
| CW100 | VA-01DA | 1 | Pipe Plug, ½” |
| CW100 | VH-18L | 6 | Castel Nut, 7/16”NF |
| CW100 | VH-11PM | 24 | Hex Head Cap Screw, ½”NC x 1 ½” |
| CW100 | VH-32K | 3 | Flat Washer, 3/8” |
| CW100 | CMA-669 | 6 | Copper Valve Gasket - HP & LP ID, 4.846OD x 5.070 x |
| CW100 | CA-299-48 | 3 | Spring |
| CW100 | VV-1001 | 1 | Air Pressure Unloader Pilot (not shown) |
| CW100 | CB-28-W | 3 | Unloader Diaphragm Assembly, 40# |
| CW100 | CB-967 | 3 | Lower Cylinder Spring |
| CW100 | CB-975 | 3 | Unloader Diaphragm Body |
| CW100 | CB-976 | 3 | Unloader Diaphragm Cap |
| CW100 | CB-979 | 3 | Grooved Unloader Pin |
| CW100 | CB-986 | 3 | Unloader diaphragm Piton Assembly, 40# |
| CW100 | CBB-917 | 3 | Unloader Fork |
| CW100 | CBA-902 | 1 | Unloader Tube |
| CW100 | CBA-903 | 1 | Unloader Tube**Furnish CBA-902 |
| CW100 | CP-616-7 | 3 | Unloader Diaphragm |
| CW100 | VH-03CF | 18 | Fillister Head Machine Screw,#10-32 x ¾” |
| CW100 | VA-14BCE | 2 | Copper Tube Connection, ¼”MPT x ¼” OD Tube |
| CW100 | VA-13BB | 1 | Short Nipple, ¼” IPT |
| CW100 | VB-406 | 1 | “O” Ring |
| CW100 | VA-11BA | 1 | Cross ¼”IPT |
| CW100 | VB-406 | 1 | “O” Ring |
| CW100 | VA-15BCE | 2 |
Copper Tube Elbow,
¼”MPT x ¼” OD Tube
|
H&K PUMP @ 214-428-2868
CURTIS CW SERIES AIR COMPRESSORS
www.hkaircompressors.com
No comments:
Post a Comment
